Operating Shafts for Pistol Handles

ABB OXP6X operating shafts are designed for use with ABB pistol handles in rotary disconnect and switch-disconnector applications. These 6 mm square shafts connect the external handle mechanism to the switch body, allowing safe operation through an enclosure door.

Available in two shaft length options, OXP6X150 and OXP6X210, these accessories are commonly used with ABB OT, OS, and OTDC disconnect switch families.

Available Options

• OXP6X150: 6 mm square operating shaft, 150 mm / 5.9 in length
• OXP6X210: 6 mm square operating shaft, 210 mm / 8.3 in length

Key Features

• Operating shaft for ABB pistol handle assemblies
• 6 mm square shaft profile
• Designed for rotary disconnect and switch-disconnector applications
• Compatible with ABB OT, OS, and OTDC accessory systems
• Used to connect the external handle to the disconnect switch mechanism
• Available in 150 mm and 210 mm lengths to suit different enclosure depths

Typical Applications

Ideal for enclosure-mounted disconnect switches, control panels, safety disconnects, and industrial electrical equipment where a door-mounted pistol handle is required to operate an internal ABB disconnect switch.

Selection Notes

Select the shaft length based on enclosure depth and the required distance between the pistol handle and disconnect switch body.

OXP6X150 is the shorter 150 mm option, while OXP6X210 provides a longer 210 mm reach for deeper enclosures or installations requiring additional shaft length.

Important Notes

Verify compatibility with the specific ABB handle, disconnect switch frame, and enclosure depth before installation.
